ZERO DSRX Swingarm
Note: The amount of items in stock reflects the amount available in the store in Antwerp, this excludes stock in other stores. If you need a product urgently and it is not in stock in Antwerp feel free to call us to see if it is available from another warehouse.
We do not use/share your data or utilise (tracking) cookies of any kind. The downside of this is that you will need to create an account and log in before you can add anything to your cart.
| Nr. in drawing | Productcode | Name | Price | Stock | Zie details |
|---|---|---|---|---|---|
| 30-08084 | GEN 2 Tem 2015 - BELT DRIVE, 220T, 8MM PITCH, 14MM WIDE, NEW LOGO | € 240.90 | 0 | ||
| 30-08278 | GEN2 SDS FX 2016-2023 ZERO Belt 158T 11x17mm thin web | € 262.91 | 2 | ||
| 30-08226 | GEN3 S,SR,SR/X BELT 151T 11MM PITCH 20MM WIDE | € 273.91 | 2 | ||
| 30-08325 | GEN3 DS DSR DSRX belt 151T 11MM 25MM | € 279.00 | 4 | ||
| 30-03657 | GEN2 2014 tem 2016 (D)S(R) motorsprocket | € 117.70 | 0 | ||
| 30-08116 | ZERO GEN2 (D)S(R) 2017-2023 DSR MOTOR SPROCKET 20T 11MM PITCH 17MM WIDE BELT 45 DEG ASSEMBLED | € 148.98 | 2 | ||
| 30-08403 | GEN 3 S,SR(X) MOTOR SPROCKET 20T 20MM BELT ASSEMBLED | € 160.64 | 0 | ||
| 30-08326 | GEN 3 DS(R,RX) MOTOR SPROCKET 22T 25MM BELT ASSEMBLY | € 180.30 | 2 | ||
| 1 | 22-08131 | REAR SHOCK 46MM ADVENTURE | € 0.00 | 0 | Contact store |
| 10 | 90-08257 | HEXAGON FLANGE BOLT DIN 6921 M8X16 10.9 ZM-F-01 ZM-L-02 | € 0.00 | 0 | Contact store |
| 11 | 26-08349 | SWINGARM BEARING CAP WITH BEARING AND INNER SEAL PRESS FIT SUBASSEMBLY | € 0.00 | 0 | Contact store |
| 12 | 23-08102 | AXLE REAR | € 0.00 | 0 | Contact store |
| 13 | 26-08246 | REAR AXLE ADJUSTER HEAD SIDE | € 0.00 | 0 | Contact store |
| 14 | 26-08305 | REAR AXLE ADJUSTER INTERNAL | € 0.00 | 0 | Contact store |
| 15 | 26-08202 | SWINGARM END CAP RIGHT | € 0.00 | 0 | Contact store |
| 16 | 90-08158 | STAR DRIVE SOCKET HEAD CAP SCREW ISO 14579 M8X50 8.8 ZM-F-01 | € 5.65 | 1 | |
| 17 | 45-07496 | MPI WHEEL SPEED SENSOR | € 68.04 | 4 | |
| 18 | 23-08116 | BEARING SPACER TUBE 5.50 X 17 REAR CAST WHEEL | € 0.00 | 0 | Contact store |
| 19 | 23-07489 | WHEEL SPACER DRIVE SIDE REAR | € 0.00 | 0 | Contact store |
| 2 | 90-08354 | HEX FLANGE BOLT STAR DRIVE PER ZM 88-08813 M10X60 10.9 ZM-F-01 ZM-L-02 | € 0.00 | 0 | Contact store |
| 20 | 26-08247 | SWINGARM END CAP LEFT | € 0.00 | 0 | Contact store |
| 21 | 26-08248 | REAR AXLE ADJUSTER NUT SIDE | € 0.00 | 0 | Contact store |
| 22 | 90-05678 | U-NUT M20X1.5 FLANGE 27S 15H | € 0.00 | 0 | Contact store |
| 23 | 90-08170 | STAR DRIVE BUTTON HEAD CAP SCREW ISO 7380 M4X8 8.8 ZM-F-01 ZM-L-02 | € 0.00 | 0 | Contact store |
| 24 | 90-07389 | TOOTHED LOCK WASHER WITH EXTERNAL TEETH DIN 6797 A M5 ZM-F-01 | € 0.00 | 0 | Contact store |
| 25 | 25-08080 | ABS MAGNET RING | € 79.38 | 0 | |
| 26 | 90-08338 | HEX FLANGE BOLT STAR DRIVE PER ZM 88-08813 M12X30 10.9 ZM-F-01 ZM-L-02 | € 0.00 | 0 | Contact store |
| 26 | 26-08527 | SWINGARM ASSEMBLY POWER PIVOT ADVENTURE SPORT | € 0.00 | 0 | Contact store |
| 3 | 90-08033 | WASHER 17.5 - 30.0 X 1.25 PLASTIC | € 0.00 | 0 | Contact store |
| 4 | 90-02100 | WASHER ISO 7089 10-200 HV ZM-F-01 | € 0.00 | 0 | Contact store |
| 5 | 90-02050 | PREVAILING TORQUE TYPE NUT DIN 985 M10-08 ZM-F-01 | € 0.00 | 0 | Contact store |
| 6 | 26-08602 | RIGHT SIDE DOUBLER ASSY | € 0.00 | 0 | Contact store |
| 7 | 26-08603 | LEFT SIDE DOUBLER ASSY | € 0.00 | 0 | Contact store |
| 8 | 12-08106 | SWINGARM JOINT SHIM SERVICE KIT | € 0.00 | 0 | Contact store |
| 9 | 26-08263 | SWINGARM BEARING DUST COVER OUTER | € 0.00 | 0 | Contact store |
